Astronomy Cameras - sCMOS, SWIR, EMCCD & CCD

Andor's product portfolio incorporates a range of high-performance detector solutions for Astronomy, from faster time resolution sCMOS and EMCCD cameras to slow scan CCDs. Across each technology category, low noise floor and back-illuminated QE options are common, as are very large area sensor solutions for maximum sky coverage. Crucially, Andor’s unparalleled commitment to superb quality, vacuum innovation and ease of maintenance is instilled throughout the portfolio, intended to maximize your observing time and to minimize cost of ownership.

iKon CCD series - Up to 16.8 Megapixel back-illuminated CCDs, including NIR optimized, with -100 °C TE cooling.
iXon EMCCD series - single photon sensitivity and > 90% QE at high speed.
sCMOS camera series - up to 4.2 Megapixel, > 90% QE options, very high-speed readout with ultra-low noise floor.
C-RED SWIR Cameras Series - Sensitivity up to 2.5 µm, Single Photon Sensitive solutions, Up to 3500 images per second.

Need help deciding?

sCMOS for Fast Time Resolution and Large Sky Surveys

Including Marana back-illuminated platform, scientific CMOS (sCMOS) technology is especially relevant for faster time resolution astronomy, combining high resolution / large field of view coverage of the sky with very fast readout capability, yet without sacrificing ultra-low noise performance, with a further key benefit of avoiding mechanical shutters. The ZL41 Wave is a superb ‘workhorse’ sCMOS for astronomy, an ideal balance of versatility and superb price/performance value. Furthermore, CB2 is the newest cost-effective, low noise and very high resolution sCMOS platform, ideally suited to large sky surveys, lucky astronomy/speckle interferometry and adaptive optics.

Large FOV up to 31.9 diagonal (4.2 Megapixel)
Extremely low noise down to 0.9 e^-
QE up to 95% (back-illuminated)
Rapid frame rates up to 1594 fps (full frame)
Multi-amplifier extended dynamic range technology
ZL41 Wave price/performance workhorse camera

Key Applications: Solar Astronomy, Orbital Debris Tracking, Solar System Objects Detection, Exoplanet Discovery, Speckle/Lucky Imaging (Large FOV), Occultations, Pulsars, Atmospheric Science, Wavefront sensors and Large Sky Surveys.

Learn More Ask a Question Need help deciding?

SWIR Cameras for Physical Science & Astronomy

We also offer a range of SWIR Cameras for Astronomy that provide superb sensitivity and speed performance across the Short-Wave Infra-Red wavelength domain. Technologies include market-leading InGaAs and the unique single photon sensitive ‘e-APD MCT’ imaging innovation.

Sensitivity up to 2.5 µm
Single Photon Sensitive solutions
Up to 3500 images per second
Deep cooled for thermal noise minimization
Imaging and Spectroscopy solutions

Key Applications: Astronomy, Adaptive Optics, Interferometry, Laser Beam Profiling, Hyperspectral Imaging, Advanced Materials and Chemistry

Learn More Ask a Question Need help deciding?

EMCCDs for Fast Time Resolution with Ultimate Sensitivity

Featuring single photon sensitivity, TE cooling to -100 °C and > 95% QE, the iXon EMCCD range has been central to many demanding, light-starved observing initiatives, such as the RAVEN ‘Multi-Object Adaptive Optics’ system at the Subaru Telescope (Hawaii), CHIMERA, the Caltech high speed multi-color camera for detecting transiting objects in the Kuiper Belt, and SOFIA (pictured).

With the single photon sensitive EMCCD cameras, Andor have delivered a dedicated, truly high-end, yet accessible scientific camera platform, designed specifically to drive the absolute best from ultra-sensitive EMCCD technology across all critical performance specs and parameters.

Single photon sensitivity
Quantum efficiency > 95%
Up to 1 Megapixel
26 - 2067 full frames per second

Key Applications: Wavefront sensors, High time resolution astrophysics,
Speckle/Lucky imaging and Occultations.

Learn More Ask a Question Need help deciding?

Large Area CCDs for Imaging and Spectroscopic Surveys

The 4 Megapixel iKon-L camera has long been the mainstay detector for many observing projects, including SuperWasp and Next Generation Transit Survey exoplanet programs.
