Andor’s SWIR and InGaAs portfolio featuring First Light Imaging cameras for Life and Physical Science research offers exceptional sensitivity and performance in capturing images across a wide range of scientific applications, with a focus on Near-Infrared (NIR) and Short-Wave Infrared (SWIR) technology. Our cameras are engineered to provide high-resolution imaging capabilities, allowing researchers to delve deeper into their scientific investigations.
C-RED SWIR Cameras are in stock and ready to ship!
SWIR Camera Features include:
Model | C-RED One | C-RED 2 | C-RED 2 ER | C-RED 2 Lite | C-RED 3 | C-RED New Space | iDus InGaAs 1.7μm | iDus InGaAs 2.2μm |
(mm) | e-APD MCT | InGaAs | InGaAs | InGaAs | InGaAs | InGaAs | InGaAs | InGaAs |
Sensor Format | 320 x 256 | 640 x 512 | 640 x 512 | 640 x 512 | 640 x 512 | 640 x 512 | 1025 x 1 512 x 1 |
1025 x 1 512 x 1 |
Pixel Size (µm) | 24 | 15 | 15 | 15 | 15 | 15 | 25 x 500 50 x 500 |
25 x 250 50 x 250 |
Wavelength Range (µm) | 0.8 - 2.5 | 0.9 - 1.7 | 1.1 - 1.9 1.2 - 2.2 |
0.9 - 1.7 | 0.9 - 1.7 | 0.9 - 1.7 | 0.9 - 1.7 | 0.9 - 2.2 |
QE max (%) | 80 | 85 | 82 (1.9) 85 (2.2) |
80 | 78 | 80 | 80 | 80 |
Cooling (°C) | -183 | -40 | -40 (1.9µm model) -55 (2.2µm model) |
25 below case temp | Uncooled | Environment Dependent | -90 | -90 |
(full array) | 3500 fps | 600 fps | 600 fps | 600 fps | 600 fps | 600 fps | 193 sps | 193 sps |
Read Noise (e-) | < 1 | 23 | 32 (1.9µm model) 36 (2.2µm model) |
28 (@ 5C cooled) | 37 | < 30 | 580 | 580 |
Darkcurrent (e-/pix/sec) | < 80 @ -183°C | 310 @ -40°C | 19,500 @ -40°C 130,000 @ -55°C |
25,000 @ +5°C | 817,000 @ +40°C | TBD | 11,000 @ -90°C | 5,000,000 @ -90°C |
Pixel Well Depth (e-) | 100,000 | 1,400,000 | 1,500,000 | 1,400,000 | 1,400,000 | 1,400,000 | 1,700,000,000 | 1,700,000,000 |
(Shutter) | Global | Global | Global | Global | Global | Global | Global | Global |
Interface | Camera Link | USB 3.1 Gen 1 Camera Link |
USB 3.1 Gen 1 Camera Link |
USB 3.1 Gen 1 Camera Link |
USB 3.1 Gen 1 Camera Link |
USB 3.1 Gen 1 Camera Link |
USB 2.0 | USB 2.0 |
Specifications | Specifications | Specifications | Specifications | Specifications | Specifications | Specifications | Specifications | |
Pricing | Pricing | Pricing | Pricing | Pricing | Pricing | Pricing | Pricing |
